Lakeside Lift standard build will enable this lift to operate in as shallow water as your boat can propel itself with full cradle travel. The Lakeside Lift standard build can accomodate up to nominally 4' water depth (depending on lake bottom surface). Additional leg extensions are available up to 13' water depth.
Features
-
15-year structural warranty (industry-leading)
2-year mechanical warranty
Stainless steel aircraft cable for lifting
Light-weight marine-grade aluminum construction
Standard leg extensions for 3'-4' deep water without compromising overall lift height
Powder-coated crank wheel and adjustable knob
Canopies in various lengths and 18 colors (vinyl)
Host of complementing accessories
| Lakeside Lift Model # | Cable Reeving | Appx. Shipping Weight | Weight Capacity (Pounds) | Overall Beam (Inches) | Overall Width (Inches) | Overall Length (Inches) | Lifting Height (Inches) | Min. Platform Height (Inches) |
|---|---|---|---|---|---|---|---|---|
| V45-116-66* | Single | 450 | 4500 | 116 | 124 | 116 | 66 | 8 |
| V55-116-66* | Double | 581 | 5500 | 116 | 124 | 116 | 66 | 9 |
| V70-124-78 | Double | 846 | 7000 | 124 | 133 | 138 | 78 | 11 |
*Also available in a 78” lift height(***)
